Walk-In Fume Hood LBN-WF162 is intended for large-apparatus applications with a maximum opening of 1300 mm. It is a large enclosure designed to isolate fumes, dust, gases, odours, and other harmful particles while maintaining a stable performance. To ensure the operator's safety, the unit includes water and gas taps, as well as gas and water control valves, a large air exhaust valve with an exhaust air flow volume of 1500m3/h, and a 5 mm toughened glass front window.
| Maximum Opening | 1300 mm |
| Exhaust Air Flow Volume | 1500m3/h |
| Inflow Air Velocity | 0.3 – 0.8 m/s |
| Noise | ≤62 dB |
| Vibration | Amplitude ≤5 µm |
| Illumination | ≥800 LUX |
| LED Lamp | 16W × 2 |
| Sockets | 4 water proof sockets |
| External Material | 1.0 mm cold rolled sheet with bacteria powder coating |
| Internal Material | Laminate board with acid and alkali resistance function |
| Power Consumption | 500 W |
| Power Supply | AC220V±10%, 50/60 Hz |
| Internal Dimension (W×D×H) | 1280 × 550 × 1670 mm |
| External Dimension (W×D×H) | 1500 × 800 × 2250 mm |
| Package Dimension (W×D×H) | 1710 × 1050 × 2450 mm |
| Gross Weight | 340 Kg |
Walk-in fume hoods are used for large laboratory applications in chemical fume control, powder and dust removal, solvent vapor control, acid gas fumes and other applications that produce hazardous particulates and fumes.
Walk-in fume hoods are used for large laboratory applications in chemical fume control, powder and dust removal, solvent vapor control, acid gas fumes and other applications that produce hazardous particulates and fumes.
Most Frequently Asked Questions
1. What are Walk-In Fume Hoods used for?
Ans. Walk-In Fume Hoods are used to safely handle large-scale experiments involving chemical fumes, powders, dust, and solvent vapors.
2. How do Walk-In Fume Hoods support large laboratory operations?
Ans. Walk-In Fume Hoods are designed with spacious interiors and high capacity filtration to manage demanding experimental workflows.
3. What filtration features are included in Walk-In Fume Hoods?
Ans. Walk-In Fume Hoods are equipped with high capacity filters to effectively capture hazardous fumes and particles.
4. How do Walk-In Fume Hoods maintain operational settings during power failure?
Ans. Walk-In Fume Hoods include built in memory functions that retain operational settings during power interruptions.
5. What utility features are available in Walk-In Fume Hoods?
Ans. Walk-In Fume Hoods feature integrated water and gas taps along with safety valves for controlled utility access.
6. Where are Walk-In Fume Hoods commonly used?
Ans. Walk-In Fume Hoods are commonly used in laboratories requiring effective chemical fume control, dust removal, and solvent vapor management.
Walk-In Fume Hood LBN-WF162 is intended for large-apparatus applications with a maximum opening of 1300 mm. It is a large enclosure designed to isolate fumes, dust, gases, odours, and other harmful particles while maintaining a stable performance. To ensure the operator's safety, the unit includes water and gas taps, as well as gas and water control valves, a large air exhaust valve with an exhaust air flow volume of 1500m3/h, and a 5 mm toughened glass front window.
