Automatic Glassware Washer LBN-GW131 is designed to be long-lasting, dependable, and energy efficient. It has a 7.1 inch true color display LCD touch screen, is simple to use, and has a 1/4 cleaning rack for easy adjustment and replacement. It has a 206 L washing chamber with upper and lower utensils reaching heights of 170 and 265 mm, respectively. The exterior is made of 304 brushed stainless steel, while the interior is made of AISI 316L stainless steel mold with special welding technology to prevent bacteria breeding.
Washing Chamber Volume | 206 L |
Cleaning Space | 195 L |
Working Environment | 5°C to 40°C |
Maximum Noise | 45 dB |
Circulating Pump Power | 0.75 KW |
Circulation Pump Flow | 430 L/min |
Water Heating Power | 4 KW |
Drying Fan Power | 1.1 KW |
Drying Heating Power | 2.4 KW |
Peristaltic Pump Plus Dosage | 360 ML/min |
Power Supply | 220V/50Hz |
Rated Total Power | 5KW |
Cleaning Chamber Size | 552×565×807 mm |
External Dimension | 909×715×998 mm |
Streamlined controller design
7.1 inch LCD touch screen
Provides 12 custom program groups that can be modified
Three level password security at different levels
Automatic fault diagnosis program
Standard 3-layer stainless steel filter can effectively trap dirt and prevent circulation pipeline from clogging
Door body is made of double transparent glass for real time cleaning observation
Two layers of cleaning baskets can be placed
Low noise operation
Maximize cleaning capabilities and reduce energy consumption
These are used vastly in research laboratories, pharmaceutical laboratories for cleaning typical lab items ranging from wide-mouth to narrow-neck glassware.
Download Catalog for Automatic Glassware Washer LBN-GW131
DownloadCavity Volume : 126 L
Layer Number of Cleaning : 1 layer (2 layers petri dish)
Cleaning Temperature : 50° - 95°C
Circulation Pump Flow Rate : 320 L/min
Cavity Volume : 126 L
Layer Number of Cleaning : 1 layer (2 layers petri dish)
Cleaning Temperature : 50° - 95°C
Drying Power : ≥1 KW
Cavity Volume : 170 L
Layer Number of Cleaning : 2 (3 layers petri dish)
Cleaning Temperature : 50° - 93°C
Circulation Pump Flow Rate : 320 L/min
Cavity Volume : 170 L
Layer Number of Cleaning : 2 (3 layers petri dish)
Cleaning Temperature : 50° - 93°C
Drying Power : ≥1 KW
Cavity Volume : 198 L
Layer Number of Cleaning : 2 (3 layers petri dish)
Cleaning Temperature : 50° - 93°C
Circulation Pump Flow Rate : 600 L/min
Cavity Volume : 198 L
Layer Number of Cleaning : 2 (3 layers petri dish)
Cleaning Temperature : 50° - 93°C
Drying Power : 2 KW
