-86℃ ULT Upright Freezer LBN-UF171 delivers reliable ultra-low temperature storage with a range from -40℃ to -86℃. It is equipped with a large LED display and a full-function control panel for precise operation and monitoring. Built with a 58L storage capacity, it features a stainless steel inner door and a color-sprayed steel exterior. Integrated with super cooling technology it ensures rapid cabinet cooling through a powerful compressor and mixed refrigerant. Our -86℃ ULT Upright Freezer can be found in blood banks, hospitals, epidemic prevention services, research institutes, and laboratories.
| Capacity | 58 L |
| Temperature Range | -40℃ to -86℃ |
| Cooling Type | Direct Cooling |
| Defrost Mode | Manual |
| Display | LED Digital |
| Insulation | PURF |
| Refrigerant | R4001(Mixed Gas) |
| Temperature Controller | Microprocessor |
| System | Auto-Cascade |
| Sensor | PTC100 |
| Compressor | 1 |
| Inner Door Material | Stainless Steel |
| Outer Material | Color Sprayed Steel |
| Castor | Universal |
| Ambient Temperature | 10 to 32℃ |
| Alarm Functions | High/Low Temperature, Power Failure, Abnormal Voltage, Sensor Error, Door Ajar, Filter Screen Check, Thermostat Failure, Low, Battery, Condenser Clean, High Ambient, Temperature, Power Failure Backup |
| Noise | 50 db |
| Current | 3.18A |
| Power Consumption | 442W |
| Power Supply | 220V 50Hz/60Hz |
| Interior Dimension (W × D × H) | 330 × 453 × 410 mm |
| Exterior Dimension (W × D × H) | 635 × 757 × 1212 mm |
| Packaging Dimension (W × D × H) | 730 × 860 × 1420 mm |
| Net Weight | 112kg |
| Gross Weight | 146kg |
Chart Recorder
Data Logger
CO2 Backup
LN2 Backup
Gloves
Access Port – 1/25mm
USB Interface – 1
Remote Alarm Access
RS485 Access
-86℃ ULT Upright Freezer LBN-UF171 is ideal for blood banks, hospitals, epidemic prevention services, research institutes, and laboratories.
-86℃ ULT Upright Freezer LBN-UF171 is ideal for blood banks, hospitals, epidemic prevention services, research institutes, and laboratories.
Most Frequently Asked Questions
1. What is the main application of the -86°C ULT upright freezer?
Ans. This freezer is engineered for the long-term preservation of biological materials such as viruses, proteins, DNA/RNA, cell cultures, and vaccines that require ultra-low temperatures for stability and integrity.
2. Is the -86°C freezer energy efficient?
Ans. Modern units use efficient compressors and insulated chambers to reduce energy consumption while maintaining stable temperatures, supporting sustainability and cost control in laboratory operations.
3. What kind of alert system does -86°C ULT upright freezer include?
Ans. An audio-visual alarm system is built in to provide quick alerts for temperature deviations, power failures, or door-open events. This ensures rapid response to protect valuable samples.
4. How easy is it to operate -86°C ULT upright freezer?
Ans. It features an accessible control panel that simplifies operation. Users can easily monitor and adjust temperature settings, check system status, and respond to alarms directly from the interface.
5. Can the interior be customized for different sample types?
Ans. Yes, the freezer includes adjustable shelves, providing the flexibility to store a wide range of materials in different-sized containers. This makes it adaptable to diverse storage needs.
-86℃ ULT Upright Freezer LBN-UF171 delivers reliable ultra-low temperature storage with a range from -40℃ to -86℃. It is equipped with a large LED display and a full-function control panel for precise operation and monitoring. Built with a 58L storage capacity, it features a stainless steel inner door and a color-sprayed steel exterior. Integrated with super cooling technology it ensures rapid cabinet cooling through a powerful compressor and mixed refrigerant. Our -86℃ ULT Upright Freezer can be found in blood banks, hospitals, epidemic prevention services, research institutes, and laboratories.
