Biological Microscope LBN-BO126 is ergonomically designed. It consists of a quadruple inward nosepiece and a viewing head with a 45° monocular inclination. It has a planar achromatic optical system as well as a coaxial coarse and fine focusing mechanism. It has an iris diaphragm with a 1.25-inch aperture and an Abbe condenser with a filter holder. It is used for sample analysis at research facilities, academic institutions, and other locations.
Optical Type | Achromatic |
Standard Magnification | 40X-1000X |
Head Type | Siedentopf trinocular |
Head Inclination | 45 degree |
Head Rotation | Head Rotate 360 degree |
Head Light Path | E100:P0/E0:P100 |
Eyepiece Diameter | 23.2mm |
Eyepiece | WF10×/18mm, 2 pcs, right tube adjustable |
Nosepiece | 4 holes, inward |
Objective | 4×, 10×, 40× (s), 100× (s, o) |
Working Stage Type | 2 Layer Mechanical |
Working Stage Size | 125 × 130mm |
Working Stage Moving | 60 × 30 mm |
Focusing Type | Coarse Coaxial & Fine, 20mm |
Condenser | 1.25 N. A |
Condenser Type | ⏀2-⏀30mm Iris Diaphragm, ⏀32mm Filter Holder |
Light Source | Halogen, brightness adjustable |
Power Supply | AC110V-220V |
Transmit Light | 6V/20W |
Weight | 20Kg |
Dimensions (L × D × H) | 690 × 450 × 470 mm |
Light Source (optional) | LED 1W, brightness adjustable |
It is simple, easy to use and reliable
It consists of an achromatic optical system
Abbe condenser type
Inward quadruple nosepiece
Coaxial coarse and fine focusing type with 20nm size
Biological Microscope is used for qualitative and quantitative analysis of samples at medical institutes, scientific research institutes, health clinics, etc
