Fluorescence Microscope LBN-FM123 is a motorized research-level zoom stereo microscope with an infinite parallel Galileo optical system.It delivers sharp, high-contrast, and true-color images using plan apochromatic objectives with wide zoom range and smooth magnification.Equipped with a trinocular head and motorized controls, it ensures easy to use and precise focusing.Integrated EPI-fluorescent attachment with 5-hole module and four-band LED illumination ensures flexible fluorescence imaging.Our product LBN-FM123 is ideal for life sciences, biomedical research, semiconductors, materials science, industrial inspection, and education.
| Optical System | Infinite Parallel Galileo Zoom |
|---|---|
| Viewing Head | 20° inclined trinocular head; switchable between binocular/trinocular (100:0 or 0:100),<br>Interpupillary Distance: 50–76 mm<br>Fixed Eyepiece tube with lock screw |
| Eyepieces | Standard: PL10×/23 mm<br>Diopter Adjustable Optional: PL15×/16 mm or PL20×/12 mm |
| Zoom Range | 0.75× – 13.5× with click stops at key magnifications (0.75, 1, 2, 3, 4, 5, 6, 8, 10, 11, 12, 13, 13.5×); built-in aperture diaphragm |
| Objective Lens | Plan Apochromatic 1×<br>Working Distance<br>60 mm<br>Numerical Aperture (N.A.): 0.15 |
| Zoom Ratio | 18:1 |
| Focusing Unit | Motorized, three-speed focusing; range: 110 mm<br>Remote control; supports coarse, fine, ultra-fine focusing; accuracy ≤0.01 mm<br>Speed 0.1 mm/s |
| Base | Plan base with transmitted LED illumination<br> Ø180 mm glass insert plate<br> OIC (Optical Image Control) function |
| Illumination | Standard: LED transmitted, brightness adjustable<br> Optional: LED Ring Light or Cold Light Source |
| Camera Adapter | 1× C-mount adapter |
| Fluorescence Attachment | EPI-Fluorescent with 5-hole turret<br>Supports up to 4 fluorescence modules + 1 bright field module<br>Four-band LED light with adjustable brightness; filters<br>FL-FITC, mCherry, V, FL-DAPI |
| Net Weight | 20 kg |
| Packing | 1 set/carton |
| Gross Weight | 22 kg |
<span style="background-color:transparent;color:#000000;">Infinite Galileo Optics</span>
<span style="background-color:transparent;color:#000000;">Large Zoom Ratio</span>
<span style="background-color:transparent;color:#000000;">Trinocular Viewing Head</span>
<span style="background-color:transparent;color:#000000;">Apochromatic Objective Lens</span>
<span style="background-color:transparent;color:#000000;">Motorized Focusing System</span>
<span style="background-color:transparent;color:#000000;">Fluorescence Module System</span>
<span style="background-color:transparent;color:#000000;">LED Illumination Source</span>
<span style="background-color:transparent;color:#000000;">Ergonomic Design</span>
<span style="background-color:transparent;color:#000000;">Camera Compatibility</span>
LED Ring light
Cold light source
Fluorescence Microscope LBN-FM123 is ideal for life science and biomedical research, live cell imaging, IVF experiments.Industrial inspection, material science, microelectronics testing, gemology, and education/training in labs.
