Fabric Air Permeability Tester LBN-AT113

Fabric Air Permeability Tester LBN-AT113

Fabric Air Permeability Tester LBN-AT113 is used to determine the air permeability of various flat materials in a quick, simple, and accurate manner. It is a fully automated instrument with a measurement range of 0 - 200 Pa/cm2 and a pressure difference range of 0 - 2 KPa that is controlled by a single chip microcomputer. The device includes an LCD screen as well as a micro-printer for quick and clear printing.

Measure Range 0 – 200 Pa/ cm2, 0 – 2000 L/dm2/min, 0 – 3000 mm/s, 0 – 3300 µm/Pas
Accuracy 0.01 Pa/ cm2, 0.1 Pa, 0.01 L/dm2/min, 0.1 mm/s
Linear Error <1%
Measuring Area 5 cm2, 20cm2, 10cm2 (selectable)
Air Flow 8 L/min (mask test)
0 – 100 L/min (fabric test)
Pressure Difference 0 KPa – 2 KPa
Power AC110 – 240V
Dimension 420×340×480 mm
Weight 32 Kg

Designed with microcomputer control

Whole test is fully automatic, fast and accurate

Adopts an intelligent chip and load sensor to increase the test accuracy

Equipped with English menu LCD screen with soft touch buttons

Micro-printer, fast and clear printing

It can set pressure difference based on the permeability of the product

Data recording and processing functions

It is widely used in testing the permeability of leather, cloth, fabric, paper, cardboard or other sheet objects etc.

Download Catalog for Fabric Air Permeability Tester LBN-AT113

Download

Labnic Low Air Permeability Tester is designed to measure airflow of materials with very low flow rates, ranging from 0 to 2500 ml/min. They deliver fast and accurate results, making it ideal for high-precision applications. These are equipped with smart chips and load sensors, ensuring reliable performance. They feature an LCD screen for easy operation and clear data visualization. Our Low Air Permeability Tester is suitable for evaluating the porosity of ultra-thin sheets, including paper and other thin materials.

Low Air Permeability Tester LBN-AT111

Low Air Permeability Tester LBN-AT111

Measurement Range : 0 to 2500 ml/min, 0.01 to 42 µm/Pas

Accuracy : 0.01 µm/(Pas), 0.06 ml/min, 0.1s

Linear Error : < 1%

Measuring Area : 6.42 cm², 10 cm² (selectable)

Low Air Permeability Tester LBN-AT112
Low Air Permeability Tester LBN-AT112

Measure Range : 0 to 400 ml/min, 0.00005 to 0.2 µm/Pas

Accuracy : 10 to 5 µm / (Pas), 3×10 4 ml/min, 0.1s

Linear Error : < 1%

Measuring Area : 50 cm² (selectable)
