Automatic ELISA Processor LBN-AEP110 is a fully automated system for sample addition, incubation, washing, and reading with dual channels and 8-channel photometric detection. It offers pressure-based liquid level and clot detection for precise, safe pipetting. Equipped with a 16-channel washing head and 4 reagent racks for efficient workflow. Integrated with 8 shaking incubators, UV disinfection, and dry heating for optimal assay performance. Our Automatic ELISA Processor is ideal for hospitals, research labs, and diagnostic centres needing high-throughput accuracy.
| Sampling Channel | 2 channels |
|---|---|
| Sample Racks | 6×20 Push-Pull Sample Racks with Detection |
| Liquid Level Detection | Air Pressure-Based with Clot Detection |
| Tip | 1000μl, 3 Tip Racks |
| Pipetting | 10μl to 1000μl |
| Pipetting Precision | 100μl: CV ≤1%, Accuracy ≤2.5%; <br>1000μl: CV ≤0.5%, Accuracy ≤1% |
| Reagent Position | 4 Reagent Racks with Detection |
| Dilution Plate Position | Available (included with plate handling system) |
| Washer | 1 unit |
| Washing Head | 16-Channel (32-pin), Double Row, Hanging Type, Leakage Recovery |
| Injection Uniformity | CV < 1.5% |
| Washing Residual | <1μl |
| Reading Channels | 8 Independent Photometric Channels |
| Linear Range | 0.000 to 3.000 Abs |
| Repeatability | CV ≤1.0% |
| Stability | ≤±0.003 Abs |
| Spectral Range | 405, 450, 492, 630 nm (standard) |
| Optical Filters | 4 Standard Filters |
| Total of Filters | 10 Filter Positions Available |
| Reading Accuracy | ≤±0.02 Abs (0.0 to 1.0 OD), <br> ≤±0.03 Abs (1.0 to 2.0 OD) |
| Sensitivity | ≥0.01 mg/L |
| Channel Difference | ≤0.02 Abs |
| Incubators | 8 Shaking Incubators |
| Cover Position | 1 (holds 8 plate covers) |
| Heating Method | Dry Heating with Cover |
| Shaking Function | Horizontal Circular Oscillation, 3 Levels, Amplitude 2.5 mm |
| Temperature Range | RT to 60°C |
| Temperature Uniformity | ±0.5°C |
| Temperature Fluctuation | ±0.5°C |
| Software | Compatible with Windows 7 and above |
| LIS System | Bi-Directional, Supports HL7 Protocol |
| Results | Absorbance and Results Viewable via software |
| Disinfection | UV Lamp |
| Lighting | LED |
| IAP Function | Firmware can be Upgraded Online |
| Operating Temperature | 10 to 40°C |
| Operating Humidity | 30 to 80% |
| Power Supply | AC 220V±10%, 50/60Hz |
| Dimensions | Machine: 1273×750×1650 mm<br> Base Stand: 1273×750×777 mm |
| Packing Dimensions (W×D×H) | Machine: 1065×895×510mm, ; <br>Stand: 1445×920×1130mm<br>Accessories: 1445×920×1005mm |
| Net Weight | Machine: 226 kg; <br>Base Stand: 98 kg |
| Gross Weight | Machine: 300 kg; <br>Base Stand: 172 kg; |
High Precision Pipetting
Dual-Thread Sampling and Pipetting
Real-Time Gripper Status Sensing
Adjustable Oscillation Incubation
TIP and Clot Detection System
High Optical Accuracy with 8 channels
Sample & Reagent Unit,
Washing Unit
Reading Unit
Incubation Unit
Automatic ELISA Processor LBN-AEP110 is ideal for hospital laboratories, disease control centres, blood banks, quarantine facilities, and scientific research institutions
