Digital Microscope LBN-DM127 utilizes the NIS45 infinite color-corrected optical system for high-quality color reproduction in images. It features a Seidentopf trinocular head with a 30° inclination, offering comfortable viewing angles. Automatically adjusts light intensity after changing the objective for optimal observing conditions. Incorporated a motorized X-Y mechanical stage for accurate sample positioning and movement. Our microscope features a front LCD touchscreen that displays magnification and illumination details.
| Optical System | NIS45 Infinite Color Corrected Optical System |
| Standard Magnification | 1000x |
| Objective Type | Apochromat |
| Head Type | Seidentopf Trinocular Head |
| Inclination | 30° |
| Interpupillary | 47mm to 78mm |
| Tube Length | 200mm |
| Diopter | Adjustable |
| Eyepiece | SW10X/25mm |
| Magnification | 5x, 10x, 20x, 50x, 100x |
| Stage | High-precision motorized X-Y double layers mechanical stage |
| Size | 275×239×44.5 mm |
| Stage Repeat Positioning Accuracy | ± 1.5 μm |
| Nosepiece | Backward Motorized Sextuple Nosepiece (with DIC slot) |
| Focusing | Low-hand motorized autofocusing mechanism |
| Focus Range | 30 mm |
| Focusing Repeat Positioning Accuracy | 0.1μm |
| Reflected Illumination | Reflected light 5W LED Koehler illumination 6-position turret BF2 bright field module DF dark field module |
| Dimensions | 261×367×582 mm |
| Weight | 27kg |
Precise electric focusing
Control via joystick, touch screen, or software
Polarized light sample analysis
Ability to examine transparent specimens
Independent operation of left and right-hand wheels
Nosepiece control panel with buttons
Dust cover
Digital Microscope is used for observing metal structures, electronics, chemicals, semiconductors, etc across institutes, labs, and industries, and more.
Download Catalog for Digital Microscope LBN-DM127
Download
