Elisa Microplate Reader LBN-MR162 is a simple and dependable reader that provides accurate and quick photometric measurements via eight channel optic fiber scanning. It is ideal for assays with wavelengths ranging from 400nm to 850nm. With a reproducibility range of 0.2%, the reader analyses 96/48-well microplates while performing 12 separate tests in one plate. For accurate reading, the unit has a 7" high resolution LCD touch screen and an 8V/50W tungsten halogen lamp.
| Wavelength Range | 400nm to 850nm |
| Microplate Type | 96/48 well plate |
| Photo Detector | Silicon photodiode |
| Reading Range | 0.000 ~ 4.000 A |
| Resolution | 0.001 A |
| Accuracy | ±0.008 A |
| Reproducibility | ≤0.2% |
| Stability | ±0.003 A |
| Standard Filters | 405,450,492,630nm & 4 optional |
| Light Source | 8V/50W controlled tungsten halogen lamp |
| Reading Speed | Single wavelength≤3s; Double wavelength≤6s |
| Shaking | Linear shaking; 3 speeds |
| Printer | Built-in thermal printer, optional external printer |
| Interface Connections | 2×USB, 1×RS232, PS2 Mouse Keyboard |
| Power Supply | 100 to 240V, 50/60Hz |
Elisa Microplate Reader is suitable for many enzymatic and colorimetric assays such as immunoassays, reporter gene assays, protein quantification, DNA quantification etc.
Elisa Microplate Reader is suitable for many enzymatic and colorimetric assays such as immunoassays, reporter gene assays, protein quantification, DNA quantification etc.
Most Frequently Asked Questions
1. What are Microplate Readers used for?
Ans. Microplate Readers are used to analyze large numbers of samples efficiently in laboratory testing and research workflows.
2. What wavelength range is supported by Microplate Readers?
Ans. Microplate Readers operate within a wavelength range of 400 nm to 850 nm for versatile assay analysis.
3. What detection modes are available in Microplate Readers?
Ans. Microplate Readers support absorbance, fluorescence, and luminescence detection modes.
4. How do Microplate Readers support efficient data handling?
Ans. Microplate Readers include automated data collection to streamline analysis and improve workflow efficiency.
5. What software features are included in Microplate Readers?
Ans. Microplate Readers are equipped with built-in software for easy data analysis and result visualization.
6. How do Microplate Readers ensure measurement accuracy?
Ans. Microplate Readers provide precise temperature control to maintain consistent and accurate assay conditions.
Elisa Microplate Reader LBN-MR162 is a simple and dependable reader that provides accurate and quick photometric measurements via eight channel optic fiber scanning. It is ideal for assays with wavelengths ranging from 400nm to 850nm. With a reproducibility range of 0.2%, the reader analyses 96/48-well microplates while performing 12 separate tests in one plate. For accurate reading, the unit has a 7" high resolution LCD touch screen and an 8V/50W tungsten halogen lamp.
